l Mango220 Main Board ( CM-C220 + CX-C220 Base) : 1ea
l 5V AC DC Adapter : 1ea
l SDHC Card 8GB (Booting Image 포함) : 1ea
l 3pin Serial Cable : 1ea
l Mini USB Cable : 2ea
l USB to Serial RS232 Module : 1ea
| Continue reading | 2015-08-03 오후 1:21:27 |
.jpg)
l Mango220 Main Board ( CM-C220 + CX-C220 Base) : 1ea
l 7inch TFT LCD with Capacitive Multi Touch Screen (1024x600) : 1ea
l 7inch TFT LCD Board(CZ-C220_7inch LCD Board ) : 1ea
l FFC/FPC 케이블 0.5mm/60P/15cm
(D Type) : 1ea
l 5V AC DC Adapter : 1ea
l SDHC Card 8GB (Booting Image 포함) : 1ea
l 3pin Serial Cable : 1ea
l Mini USB Cable : 2ea
l USB to Serial RS232 Module : 1ea
l Mango 아크릴 Case : 1ea
| Continue reading | 2015-08-03 오후 12:25:22 |
가격 : 165,000원 ( VAT별도 )
Email : help@crz-tech.com ( 031-701-5057)
Package Contents
l CM-AM335x-ST CPU
Board+ CX-AM335x-ST Board : 1ea
l AC/DC Adapter :
1ea
l SDHC Card 8GB
(Booting Image 포함) : 1ea
l USB to Serial
UART Module : 1ea
l Mini USB Cable :
2ea
l 4Pin Cable : 1ea
| Continue reading | 2015-07-17 오후 5:32:55 |
가격 : 140,000원 ( VAT별도 )
Email : help@crz-tech.com ( 031-701-5057)
| Continue reading | 2015-06-26 오후 9:47:39 |
l CPU : Samsung S5PV310 ARM Cortex A9 1GHz/1.3GHz
Application Processor
l Memory : DDR3 SDRAM 2GByte(2Gbit x 8), SCL NAND
Flash 256Mbyte
l Display :
ü 7 WVGA(800x480) Color TFT with Touch
ü 7” 1024x600
(4point Touch)
ü 10.1” 1280x800
(10Point Touch)
l Audio : Wolfson WM8960 Audio Codec
l Ethernet : SMSC LAN9220 10/100Mbps
l USB Host 1.1 : 1 Port
l USB device 2.0 : 1 Port
l SD : Port2(SD/MMC boot), Port3(Wifi or Expansion)
l UART : Port 1(Debug) , Port 2 (RS232), Port
3(Expansion)
l Camera : 2 Port Support (1.3M, 5M Pixel AF Camera)
l HDMI : 1.3V(1080p Full HD)
l Wifi : SDIO, 802.11BGN Support, BT : Uart0, SDIO
l SATA : SATA 2.0 Support(Option)
l Button : Reset : 1ea , Button : 4 ea
l LED Indicator : 2ea
l Power : DC-JACK 5V,2A
l Dimensions : CPU 72mm(W) * 70.5 mm(H) Base
160mm(W) * 90 mm(H)
| Continue reading | 2015-06-03 오후 10:39:18 |
l CPU :Samsung S5PV310 ARM Cortex A9
1GHz/1.3GHz Application Processor
l Memory : DDR3 SDRAM 2GByte(2Gbit x 8),
SCL NAND Flash 256Mbyte
l Display :
l 7 WVGA(800x480) Color TFT with Touch
l 7” 1024x600 (4point Touch)
l 10.1” 1280x800 (10Point Touch)
l Audio : Wolfson WM8960 Audio Codec
l Ethernet : SMSC LAN9220 10/100Mbps
l USB Host 1.1 : 1 Port
l USB device 2.0 : 1 Port
l SD : Port 0 (SD/MMC), Port1(SD/MMC),
Port2(Expansion), Port3(Wifi)
l UART : Port 0(Bluetooth or Expansion),
Port 1(Debug) , Port 2(Expansion)
l Camera : 2 Port Support (1.3M, 5M
Pixel AF Camera)
l HDMI : 1.3V(1080p Full HD)
l Wifi : SDIO, 802.11BGN Support, BT :
Uart0, SDIO
l SATA : SATA 2.0 Support(Option)
l Button : Reset : 1ea , Button : 4 ea
l LED Indicator : 2ea
l Power : DC-JACK 5V,2A
l Dimensions : 120mm(W) * 90 mm(H)
| Continue reading | 2015-06-03 오후 10:21:59 |
l CPU : ARM1176JZF-S 533/667MHz Samsung S3C6410
l Memory : 128Mbyte Mobile DDR , SCL NAND Flash 256Mbyte
l Display : 7: WVGA(800x480) Color TFT with Touch
l Audio : Wolfson WM8960 Audio Codec
l Ethernet : SMSC LAN9220 10/100Mbps
l USB Host 1.1 : 1 Port
l USB device 2.0 : 1 Port
l SD : Port 0 (SD/MMC), Port1(Wifi), Port2(Expansion)
l UART : Port 0(Bluetooth or Expansion), Port 1(Debug) , Port
2(Expansion) , Port 3(GPS or Expansion)
l Camera : CCIR601/656 Standard Camera Interface
l Button : Reset : 1ea , Button : 2ea
l LED Indicator : 2ea
l Power : DC-JACK 5V,2A
l Dimensions : CPU 60mm(W) * 40 mm(H)
Base 130mm(W) * 85 mm(H)
| Continue reading | 2015-06-03 오후 9:55:43 |
l Processor : Exynos 5250 ARM Cortex A15
1.7GHz Application Processor
l RAM : LPDDR3 2Gbytes(2Gbitx8)
l Display : 1280x800, 800x480 Color TFT
with Touch Screen Interface
l Audio : Wolfson WM8960 Audio Codec with 1W Stereo
Speaker Amplifier
l Ethernet : 10/100Mbs SMSC9220 IC
l USB : USB 3.0 Host , USB 2.0 OTG
l SD 3.0 : SD/MMC Port 0 , 1 Standard SD
Connector
l SD 3.0 : SD/MMC Port 2 Boot , Port 3 WiFi
& Expansion Connector
l eMMC : Port1 4.5
l UART Port0 : BT & Expansion Connector
l UART Port 1 : RS232
l UART Port 2 : D-SUB9 DEBUG
l HDMI : V1.4(1080p Full HD)
l Camera : CAM Port 2 1.3M, 5M Pixel AF Camera
l MIPI : Port 2
l Dimensions : 170 x 104 mm
| Continue reading | 2015-06-03 오후 7:49:52 |
삼성 533MHz 고성능 ARM9EJ-S Application Processor 탑재 개발 보드
Samsung S3C2450 (ARM926EJ-S Application Processor) Development Board
Firmware, RTOS (eCoS외 기타), Widows CE 6.0, Linux 지원
USB Host, USB Device, 10/100 Mbps Ethernet, microSD socket, Audio Codec 기본 지원
WIFI/Bluetooth, 각종 TFT LCD, 각종 Sensor (가속도, 자이로, 기압, 리모콘 등), Camera 인터페이스 확장 지원
| Continue reading | 2015-06-03 오후 4:57:51 |
l ARM1176 삼성 S3C6410 Processor
탑재
l firmware, RTOS, Linux, Android 공부에 적합
l 카메라, WiFi / BT 드라이버 공부 및 각 종 센서 연결하여 드라이버 공부에 적합
l Mobile
DDR 128Mbytes
l SLC
NAND Flash 256Mbytes
l NOR
Flash 4Mbytes
l Display
: RGB LCD 지원
l Audio
: WM8960 Audio Codec 내장
l Ethernet
: 100Mbps Base SMSC9220 이더넷
l USB
: USB 1.1 Host 지원, USB 2.0 Device 지원
l SD/MMC
: 3개 채널 지원
l SPI
x 2 Port
l UART
x 4 port
l JTAG
: Standard ARM JTAG 인터페이스 지원
l CAMERA
: ITU601 /656 8bit Mode
l Key
: 4 x Keys, 1 x Reset Key
l LED
x 2
| Continue reading | 2015-06-03 오후 2:55:45 |
l CPU : Samsung S5PV210 ARM Cortex A8
, 800Mhz/1GHz Application Processor
l Memory : Mobile DDR2 512Mbytes ,
SLC NAND Flash 256Mbytes
l Connectors(80X4)
: IrDA, Camera, I2S, SPI0/SPI1, SDIO0/2, EBI, UART, LCD,ETC
l Dimensions : CPU 75 x 55 mm Base 145 x 95 mm
| Continue reading | 2015-06-03 오후 1:59:19 |
